Induction Motor - How to Determine the Efficiency?



Theory and Circuit Diagram

The no-load test or open-circuit test of an induction motor enables us to determine the efficiency and the circuit parameters of the equivalent circuit of the 3-phase induction motor. The circuit arrangement for the no-load test of the induction motor is shown in the figure.

Theory and Circuit Diagram

In the no-load test, the motor is uncoupled from the load and the rated voltage at the rated frequency is applied to the stator of the motor to run it. To measure the input power, two-wattmeter method is used.

A voltmeter and an ammeter being connected as shown in the circuit diagram (see the figure). The voltmeter reads the rated supply voltage, while the ammeter measures the no-load current of the motor.

Since the no-load current of the induction motor is about 20-30% of the rated current, thus the I 2R losses in winding may be neglected. Therefore, at no-load, the total input power to the motor is equal to core loss, friction and windage losses of the motor, i.e.,

$$\mathrm{P_{0} \:=\: P_{i} \:=\: P_{C} \:+\: P_{fw}}$$

$$\mathrm{P_{0} \:=\: P_{i} \:=\: \text{ Sum of two wattmeter readings } \:=\: W_{1} \:+\: W_{2}}$$

As the power factor of the induction motor under no-load is less than 0.5, so one wattmeter will give negative reading. Therefore, it is necessary to reverse the direction of the current-coil terminals to obtain the correct reading.

Now, if

  • ViL = Input Line Voltage
  • Viph = Input Phase Voltage
  • Pi.NL = Input Three Phase Power at No Load
  • I0 = No load Input Line Current

Then,

$$\mathrm{P_{i.NL} \:=\: \sqrt{3} \: V_{iL} I_{0} \: \cos \varphi_{0}}$$

The magnetising component of the no-load current is,

$$\mathrm{I_{m} \:=\: I_{0} \: \sin \varphi_{0}}$$

The core loss component of no-load current is,

$$\mathrm{I_{w} \:=\: I_{0} \: \cos \varphi_{0}}$$

$$\mathrm{R_{0} \:=\: \frac{V_{iph}}{I_{w}}}$$

$$\mathrm{X_{0} \:=\: \frac{V_{iph}}{I_{m}}}$$

Separation of Friction and Windage Losses

The friction and windage losses of the motor can be separated from the no-load losses (P0). For this, a number of readings of P0 at no-load is taken at different stator applied voltages at rated frequency. A graph is plotted between the P0 and V as shown in the figure below.

Separation of Friction and Windage Losses

Here, the curve is parabolic at normal voltages, since the iron losses are almost proportional to the square of the flux density and hence, the applied voltage. Now, the curve is extended to the left to cut the vertical axis at point M. At the vertical axis V = 0 and hence, the intercept OM represents the voltage independent losses which are the losses due to the friction and windage (Pfw).
