Swinburne Test of DC Machine



Swinburne's test is an indirect method of testing DC machines, named after Sir James Swinburne. In this method, the losses are determined separately and the efficiency at desired load is predetermined. The Swinburne's test is the simplest method of testing of shunt and compound DC machines which have constant field flux.

The connection diagram is shown in the figure and the machine is run as a motor at rated voltage and speed.

Swinburnes Test of DC Machine

Let,

V = Supply voltage

I0 = No load line current

Ish = Shunt field current

$$\mathrm{\therefore \: \text{ No load armature current, } \: I_{a0} \: = \: I_{0} \: - \: I_{sh}}$$

And

$$\mathrm{\text{No load input power } \: = \: VI_{0}}$$

This no-load input power of the machine supplies the following −

  • Core loss
  • No-load armature cu loss
  • Friction and windage losses

At no-load the useful mechanical output of the machine is zero, thus the no-load input power is only used to supply the losses in the machine. Hence,

$$\mathrm{\text{Armature cu - loss at no - load } \: = \: (I_{a0})^2R_{a}}$$

Where, Ra is the resistance of armature winding.

Therefore, the constant power losses in the machine will be,

$$\mathrm{P_{C} \: = \: \text{ No load input power - No load armature cu loss}}$$

$$\mathrm{\Rightarrow \: P_{C} \: = \: VI_{0} \: - \: (I_{a0})^{2}R_{a}}$$

Now, after knowing the constant losses of the machine, its efficiency at any other load can be determined as follows −

Consider "I" is the load current at which the efficiency of the machine is to be calculated.

Efficiency when Running as Motor

Here,

$$\mathrm{\text{Armature current, } \: I_{a} \: = \: I \: - \: I_{sh}}$$

$$\mathrm{\text{Motor input power } \: = \: VI}$$

$$\mathrm{\text{Armature Cu loss } \: = \: I_{a}^{2}R_{a} \: = \: (I \: - \: I_{sh})^{2}R_{a}}$$

$$\mathrm{\therefore\: \text{Total losses in the machine } \: = \: (I \: - \: I_{sh})^{2}R_{a} \: + \: P_{C}}$$

Where, PC is the constant losses which is determined above.

Therefore,

$$\mathrm{\text{Efficiency of Motor, } \: \eta_{m} \: = \: \frac{Output}{Input} \: = \: \frac{Input \:-\: Losses}{Input}}$$

$$\mathrm{\Rightarrow \: \eta_{m} \: = \: \frac{VI \: - \: (I \: - \: I_{sh})^{2}R_{a} \: - \: P_{C}}{VI}}$$

Efficiency when Running as Generator

Here,

$$\mathrm{\text{Armature current, } \: I_{a} \: = \: I \: + \: I_{sh}}$$

$$\mathrm{\text{Generator output power } \: = \: VI}$$

$$\mathrm{\text{Armature Cu loss } \: = \: I_{a}^{2}R_{a} \: = \: (I \: + \: I_{sh})^{2}R_{a}}$$

$$\mathrm{\therefore\: \text{Total losses in the machine } \: = \: (I \: + \: I_{sh})^{2}R_{a} \: + \: P_{C}}$$

$$\mathrm{\text{Efficiency of Generator, } \: \eta_{g} \: = \: \frac{Output}{Output \: + \: Losses} \: = \: \frac{VI}{VI \: + \: (I \: + \: I_{sh})^{2}R_{a} \: + \: P_{C}}}$$

Advantages of Swinburne's Test

Following are the advantages of Swinburne's test −

  • The power required for the testing of large machines is very small, therefore it is an economical and convenient method of testing DC machines.
  • As the constant losses are known, thus the efficiency can be pre-determined at any load.

Disadvantages of Swinburne's Test

The main disadvantages of the Swinburne's test are −

  • The change in iron losses is not considered from no-load to full load. At full load, due to the armature reaction, the flux is distorted which increases the iron losses.
  • Since the Swinburne's test is performed on no-load, thus it does not indicate whether the commutation on full load is satisfactory and whether the temperature rise would be within specified limits.

Limitations of the Swinburne's Test

The Swinburne's test has the following limitation −

  • The Swinburne's test is only applicable only to those DC machines in which the flux is practically constant, which are shunt machines and level compound generators.
  • The series DC machines cannot be test by Swinburne's test since they cannot be run on no-load and their flux and speed very greatly.
